5.1
UL 認証に関する注意事項
5.2
接続部のピン配置
6
コミッショニング
6.1
検出距離の設定
8022570.1FBN/15.09.2022 | SICK
記載内容につきましては予告なしに変更する場合がございますのであらかじめご了承ください。
The device shall be supplied from an isolating transformer having a secondary
overcurrent protective device that complies with UL 248 to be installed in the
field rated either:
a)
max 5 amps for voltages 0 ~ 20 V (0 ~ 28.3 V peak), or
b)
100 / Vp for voltages of 20 ~ 30 V (28.3 ~ 42.4 V peak).
Alternatively, they can be supplied from a Class 2 power supply.
UL Environmental Rating: Enclosure type 1
ピン配置の概要
表 1: ピン配置
WTT4SLC
-3X32xxAxx
1
2
3
4
Q1
検出距離の設定
-3X22xxAxx
+ (L+)
MF
- (M)
Q
/C
1
4
3
1
2
white background (90%)
Example:
Sensing range on black, 6%,
x = 800 mm, y = 60 mm
取 扱 説 明 書 | PowerProx Mini - WTT4SLC
取扱説明書
-3X11xxAxx
1 = 茶色
2 = 白色
3 = 青色
4 = 黒色
0.14 mm
2
AWG26
x
y
101
