Installing user modules

The remote console is connected to the
connected to the computer module can be operated from this console.
Establishing a connection to a local management network
Transmission 1 Transmission 1 Transmission 2 Transmission 2
Service Service
NOTE: If desired, connect this network interface to a local network. This enables
you to access the Config Panel
log messages to this network.
Network: Insert a category 5 twisted pair cable (or better), which is available as acces-
sory. Connect the other end of the cable to the local network.
Connecting keyboard and mouse of consoles
Line Out Line Out Serial Serial
Keyb./Mouse: Connect the mouse and/or the keyboard of the console to this interface.
In the default settings, you can connect additional USB input devices, USB
Generic:
mass storage devices, and/or a supported display or tablet to this interface.
Activate the generic USB
mode on page 41) if you want to connect another USB input device or USB mass
storage device. In this mode, any data of the USB device is not altered when transmitted
to the computer module.
IMPORTANT: If the generic USB
keyboard connected to the
VisionXS-IP-CON
Network Pwr Main Power Pwr Main Power
web application from this network and to send sys-
Generic Keyb./Mouse
mode (see (De)Activating an USB keyboard or the »Generic USB«
mode is active, the OSD cannot be operated by a
socket.
Generic
user module. The computer
Red. Power Red. Power
DP Out DP Out
G&D VisionXS-IP-C-DP-UHR · 10
Installation
