Installation
Connecting the console monitor
Line Out Line Out Serial Serial
Connect the console monitor.
DP Out:
Connecting audio and RS232 interfaces (depending on model)
Line Out Serial
Line Out: Connect the speakers or another audio output device.
Serial: Connect the serial end device to this interface.
Establishing a connection to the Gigabit Ethernet
Transmission 1 Transmission 2 Transmission 2
Transmission 1: Plug a category 6 (or better) twisted pair cable, which is available as
accessory, into this interface. Connect the other end of the Gigabit Ethernet.
NOTE: The activation of the
interface.
Use this interface to establish a redundant transmission connection (link aggregation)
with the Gigabit network.
11 · G&D VisionXS-IP-C-DP-UHR
Generic Generic Keyb./Mouse Keyb./Mouse
Generic Generic Keyb./Mouse Keyb./Mouse
Service Service Network Network Pwr Main Power Pwr Main Power
Transm. Redundancy
DP Out
DP Out DP Out
Red. Power Red. Power
