Establishing a KVM-over-IP™ connection for the first time
Establishing a KVM-over-IP™
connection for the first time
IMPORTANT:
If you use the KVM extender as a matrix module with the IP matrix
switch ControlCenter IP
the web application of the IP matrix switch (see instructions for the web application
of the IP matrix switch).
Manual configuration as described in this chapter is not necessary in this case.
G&D's
KVM-over-IP™
computer and the user module using a Gigabit Ethernet (layer 3).
The communication between two modules requires various settings. In the default
settings, the modules are configured in a way that a computer and a user module
can immediately establish a direct connection.
All computer modules are preconfigured with the IP address
modules with the IP address
IMPORTANT: Change the default IP addresses before integrating several computer
or user modules into the productive network.
ADVICE: If you do not know the IP address of an already configured user or com-
puter module, it can be determined via the log messages of the device. For more
information, see the section Determining network settings via service port on page 55.

Default setting of the modules

The default setting of the modules allows users to quickly establish a direct connec-
tion between a computer and a user module. The OSD lets you adjust the configura-
tion of both modules after their initial operation.
Both the IP addresses and the
DEFAULT SETTING OF THE COMPUTER MODULE (CPU)
IP address:
Netmask
Control port:
Communication port:
Data port:
15 · G&D VisionXS-IP-C-DP-UHR
, you can conveniently set up the
technology makes it possible to transmit signals between the
.
172.17.0.11
KVM-over-IP
172.17.0.10
255.255.0.0
18246
18245
18244
KVM-over-IP™ connection
settings are preconfigured as follows:
via
, all user
172.17.0.10
