Pin assignment of the RS232 socket/interface

The following figures show the pin assignments of the RS232 plug as well as the
RS 232 socket:
User module
1 2
6
RS232 plug
The table shows how the different lines of the data connection are assigned to the
according pins:
Pin no. Line
1 DCD (Data Carrier Detect)
2 RxD (Receive Data)
3 TxD (Transmit Data)
4 DTR (Data Terminal Ready)
5 GND (Ground)
6 DSR (Dataset Ready)
7 RTS (Request to Send)
8 CTS (Clear to Send)
9
not occupied
57 · G&D VisionXS-IP-C-DP-UHR
5
3 4
7 8 9
Computer module
5
4 3 2
9 8 7 6
RS232 socket
User module
Input
Input
Output
Output
Ground
Input
Output
Input
n/c
1
Computer
module
Output
Output
Input
Input
Ground
Output
Input
Output
n/c
