BNI IOF-329-P02-Z038
Safe I/O Module, Safety over IO-Link
IP67 Module
12

Linking PROFIsafe process data with program modules

12.1 Address ranges

80 english
The address ranges for input and output data for the safe I/O module can be set to the desired
values in the Device overview display. In the following all the address calculations are made in
bytes.
Figure 78: TIA, address ranges
Figure 79: Step7, address ranges
