English (GB) Installation and operating instructions
Original installation and operating instructions.
CONTENTS
1. Safety instructions
1.1 Symbols used in this document
1.2 Safety advice for handling chlorine
1.3 Protective equipment
1.4 First aid in case of accidents
1.5 Handling chlorine containers
1.6 Chlorine rooms
2. Introduction
2.1 Correct usage
2.2 Inappropriate usage
2.3 Qualification of the users
2.4 Responsibilities of the operator
2.5 Maintenance and service personnel
2.6 Type key of the VGA-111 vacuum regulator
2.7 Transport and storage
2.8 Unpacking
3. Technical data
3.1 General technical data
3.2 Connections
3.3 Accessories
3.4 Dimensions
3.5 Physical and chemical data of chlorine
4. Design and function
4.1 Description of the device
4.2 Functional principle
5. Assembly and installation
5.1 Selection of vacuum lines
5.2 Connecting the vacuum regulator
5.3 Connecting the liquid trap (option)
5.4 Installation example
6. Startup
6.1 Checking the tightness
6.2 Chlorine extraction
7. Operation
7.1 Switching on the chlorine gas dosing system
7.2 Changing the chlorine container while the system is
running
7.3 Switching off the chlorine gas dosing system
8. Maintenance
9. Fault finding
10. Disposal
Warning
Prior to installation, read these installation and
operating instructions. Installation and operation
must comply with local regulations and accepted
codes of good practice.
4

1. Safety instructions

These installation and operating instructions contain important
information for the user of the product:
Page
• Technical data
• Instructions for commissioning and use
4
4
• Safety instructions
4
If you require further information, or if problems occur that are not
5
described in detail in this manual, please contact Grundfos.
5
6

1.1 Symbols used in this document

7
This manual contains the following standardised safety
8
instructions about possible residual risks:
8
8
Warning
8
If these safety instructions are not observed, it may
8
result in personal injury.
8
9
If these safety instructions are not observed, it may
Caution
9
result in malfunction or damage to the equipment.
9
Notes or instructions that make the job easier and
10
Note
ensure safe operation.
10
10

1.2 Safety advice for handling chlorine

10
10
1.2.1 Hazards of chlorine gas
11
12 Warning
12
Toxic by inhalation.
12
Irritating to eyes, respiratory system and skin.
14
• Causes whooping cough, dyspnoea and lacrimation.
14
• Has a slight paralysing effect to the central nervous system.
15
15 • Concentrations of more than 10 ppm chlorine gas in the
respiratory air mean an acute danger to life.
15
• Inhaling air with a high concentration of chlorine gas for a long
16
time is lethal.
16
17
1.2.2 Hazards of liquid chlorine
18
• Causes burns of skin.
18
• Causes reddening and blistering of skin.
18
1.2.3 Rules of conduct
18
• Change chlorine containers only with gas mask.
18
• Enter contaminated rooms only with protective suit and
19
compressed-air respirator.
19
• In case of flight wear gas mask, if possible. Observe wind
direction.
