Ergänzungsbetriebsanleitung CANopen

1.7.5 Alarm Action Area for Measurement Devices (404 )

Index Sub
6519h 1
6529h 1
6539h 1
6549h 1
6559h 1
6569h 1
6579h 1

1.7.6 EMERGENCY

Tab. 8: Emergency Object Data:
Byte 0
Content* Emergency Error
Code*
Tab. 9: *
Content (1 Byte):
Emergency Error Code (2 Byte):
Error Register (1001h-Inhalt) (1 Byte):
Manufacturer specific Error Field (5 Byte):
Emergency ErrorCode (2 Byte):
18
Name Typ
Al2_action =0 U8
inaktiv
Al3_action U8
Al4_action U8
Al5_action U8
Al6_action U8
Al7_action U8
Al8_action U8
1 2 3
Error Manufacturer specific Error Field*
register*
Tab. 10: Manufacturer specific Error Field (5 Byte):
Byte #3:
Byte #4:
Byte #5:
Byte #6:
Byte #7:
Beschreibung
Level min warning
Batch error
Cal warning
Sys error
Nicht Bus
add2
add3
4 5
80h+Node-Id
0x1000 (0x10xx = Generic Error)
0x0000 (0x00xx = No Error)
0x81 (Bit #0=Generic Error,Bit #7= Manufacturer
specific)
Byte #3: Komponent-Nr. (Kanal)
Byte #4: Fehler-Typ
Byte #5: Fehler-Klasse
Byte #6: frei
Byte #7: frei
0xFF01 (0xFFxx = Device specific)
Komponent-Nr. (Kanal)
Fehler-Typ
Fehler-Klasse
frei
frei
Categ. Attr
RW
RW
RW
RW
RW
RW
RW
6 7
