Operating the Endobody Clamp
To perform setup, disassembly, and cleaning of the coupler, the
endobody clamp (or "endoclamp") must be depressed and/or
released.
• To depress the endoclamp, push down as illustrated by the down
arrow.
• To release the endobody clamp, release pressure on the clamp
and allow the spring to push the clamp into its original position, as
illustrated by the up arrow.
Setting Up the Coupler
When attaching or removing the coupler, grip only the rear
adapter, as twisting other parts of the coupler with force
may result in mechanical damage.
Do not overtighten the coupler, as this may damage the
front window of the camera.
1. Gripping the rear adapter, screw the coupler clockwise onto the
camera head until it forms a tight seal.
EN-2
