Danfoss VLT Lift Drive LD 302 Produkthandbuch Seite 89

Spezifikationen
Motor Leistungs- Strom
PM-Typ P [kW]/[hp] I [A]
Ziehl Abegg Par 1-20 Par. 1-24
SM160.30 5.6/7.5 12.5
SM160.40 3.7/5 8.7
SM160.40 4.6/6.2 10.5
SM160.40 5.8/7.8 13
SM160.40 7.4/9.9 16.5
200.15B-20 1.6/2.1 5.3
200.15B-20 3.2/4.3 9.5
200.15B-20 3.5/4.7 9.5
200.15B-20 4.3/5.8 11.5
200.15B-20 4.9/6.6 13
200.15B-20 5.7/7.6 14
200.20B-20 2.1/2.8 6.7
200.20B-20 4.2/5.6 10.8
200.20B-20 4.7/6.3 11,7
200.20B-20 6.5/ 16
200.20B-20 7.5/10.1 17.5
200.30B-20 3.3/4.4 10.5
200.30B-20 4.8/6.4 13
200.30B-20 6.7/9 17
200.30B-20 7.6/10.2 19
200.30B-20 10.3/13.8 25
200.30B-20 10.7/14.3 25
700.09AL-30 3/4 7.6
700.09AL-30 5/6.7 11.5
700.12AL-30 4.5/6 11.5
700.12AL-30 7.5/10.1 18
700.12AL-30 12/16.1 29
700.12AL-30 13/17.4 32.5
700.14AL-30 5.5/7.4 13
700.14AL-30 8.5/11.4 20.5
700.14AL-30 14/18.8 33.5
700.14AL-30 15/20.1 36.5
700.14AL-30 17/22.8 40.5
700.14AL-30 17.5/23.5 43
700.16AL-30 6.5/8.7 16.5
700.16AL-30 10/13.4 25
700.16AL-30 16/21.4 41.5
700.16AL-30 17.5/23.5 49
700.16AL-30 18/24.1 50
700.16AL-30 20/26.8 50
700.16AL3-30 7.2/9.7 19
700.16AL3-30 11.6/15.5 29
700.16AL3-30 18.8/25.2 48
700.16AL3-30 20/26.8 55
860.28AL-30 9.2/12.3 25.5
860.28AL-30 17/22.8 43
860.28AL-30 22/29.5 53.5
860.28AL-30 30/40.2 68.5
860.28AL-30 37/49.6 80.5
860.28AL-30 36/48.3 80
MG34X103
Produkthandbuch
Umdrehung Drehmoment Widerstand
N [1/min] T [Nm]/[lb-ft] R1 [Ohm]
Par. 1-25 Par. 1-26 Par. 1-30
384 140/103 1,082
192 185/136 2,581
240 185/136 1,719
300 185/136 1,147
384 185/136 0.733
84 180/133 9.51
168 180/133 2.7
186 180/133 2.7
186 220/162 2.7
258 180/133 1,776
300 180/133 1,329
84 240/177 7.04
168 240/177 2.79
186 240/177 2,267
258 240/177 1.31
300 240/177 0.992
84 380/280 4.09
120 380/280 2.54
168 380/280 1.58
192 380/280 1.24
258 380/280 0.71
258 340/251 0.551
60 500/369 4.616
96 500/369 2.09
60 750/553 1.833
96 750/553 0.779
156 750/553 0.288
168 750/553 0.238
60 850/627 1,833
96 850/627 0.779
156 850/627 0.288
168 850/627 0.238
192 850/627 0.189
240 700/516 0.115
60 1000/738 1,333
96 1000/738 0.555
156 1000/738 0.201
168 1000/738 0.159
192 900/664 0.121
240 800/590 0.093
60 1150/848 1,333
96 1150/848 0.555
156 1150/848 0.201
168 1150/848 0.159
40 2200/1623 1,244
75 2200/1623 0.418
96 2200/1623 0.28
132 2200/1623 0.168
160 2200/1623 0.124
180 1900/1401 0.085
Danfoss A/S © Ver. 2013-12-04 Alle Rechte vorbehalten.
Induktivität Motorpolzahl Gegen-EMK
Ld [mH] eine Nummer V/1000 U/min
Par. 1-37 Par. 1-39 Par. 1-40
5.6 20 626
14.9 20 1180
10.1 20 973
6.6 20 796
4.2 20 626
58.2 20 1977
16.8 20 1061
16.8 20 1060
16.8 20 1060
10.6 20 845
6,9 20 732
45.5 20 2060
17.4 20 1267
14.9 20 1181
8.3 20 885
6.6 20 784
31.8 20 2121
20 20 1687
12.1 20 1318
9.7 20 1180
5.4 20 885
4.2 20 952
73.7 30 3996
33.4 30 2691
33.8 30 3921
14 30 2518
5.2 30 1537
4.3 30 1403
33.8 30 3921
14 30 2518
5.2 30 1537
4.3 30 1403
3.5 30 1269
2.2 30 980
25.9 30 3691
11 30 2402
4 30 1442
3.1 30 1287
2.4 30 1115
1.8 30 961
25.9 30 3691
11 30 2402
4 30 1442
3.1 30 1287
30.3 30 5091
10 30 2980
6.8 30 2402
4.1 30 1883
3 30 1614
2.1 30 1346
