→ The component is deleted.

7.4.3 Connecting component with multiple devices

The connection for a component can be stored on more than one device. However, only one
device can be connected to the component at one time.
If there is an existing connection between the component and a different device, the following
information appears while the connection is being established with the current device:
Connect to this component?
Component was connected to
another device.
Establish connection?
Cancel

8 Use

8.1 Movement patterns in basic mode (mode 1)

8.1.1 Standing

Knee control through high hydraulic resistance and static alignment.
A stance function can be enabled using the adjustment software. Please see
the following section for further information on the stance function.

8.1.1.1 Stance function

INFORMATION
To use this function, it must be enabled by the O&P professional. It also has to be activated
using the Cockpit app (see Page 70).
The stance function is a functional supplement to the basic mode. This function makes it easier
for the user to stand on an inclined surface for a longer time. The joint is fixed in the flexion direc­
tion at a flexion angle between 5° and 65°.
The type of joint locking (intuitive/manual) has to be established by the O&P professional. Chan­
ging the locking type using the Cockpit app is not possible.
Intuitive locking of the joint
The intuitive stance function recognises any situation that puts strain on the prosthesis in the flex­
ion direction but where flexion is not permitted. Examples of this include standing on uneven or
sloping surfaces. The knee joint is always locked in the flexion direction when the prosthetic leg is
not fully extended and is kept still for a brief moment. Upon forward or backward rollover or exten­
sion, the level of resistance is immediately reduced to stance phase resistance again.
The knee joint is not locked when the above conditions are met and a sitting position is assumed
(for example while driving).
The stance function can also be set manually to any flexion angle between 5° und 65° (see the
next section).
Manual joint lock
1) Flex the joint between 5°and 65° and keep it still for one second.
66
► Tap the OK button.
→ The connection to the last connected device is broken off
and established with the current device.
OK
