AVENTICS | CL03, CL03-XL | R402000141–BAL–001–AF
8.2

Adding additional valve positions

One or more valve positions can be attached on the right
of the valve system to equip it with valves or blanking plates.

8.2.1 Installation regulations

The maximum number of subbases for parallel actuation
of valves is two valve positions per valve system.
The maximum number of 16 valve positions must not
be exceeded for the CL03 valve system.
The maximum number of 18 valve positions must not
be exceeded for the CL03-XL valve system.
– For 17 valve positions, at least one subbase must be used
for parallel actuation of valves.
– For 18 valve positions, at least two subbases must
be used for parallel actuation of valves.
The seals (5) for CL03 and CL03-XL are identical.
8.2.2 Disassembling the valve system
1. Make sure the relevant system part is not under voltage
or pressure.
2. Remove the valve system from the mounting surface.
Conversion and Extension
