AVENTICS | CL03, CL03-XL | R402000141–BAL–001–AF
5.7

Mounting the multipole plug

1. Make sure the seal is inserted in the slot.
2. Then place the plug so that connection is secured.
3. Fix the multipole plug cover by fastening the four hexagon
screws.
Tightening torque: 1.0–1.2 Nm
Wrench size: 7 mm.
6

Commissioning

Commissioning may only be carried out by qualified
electrical or pneumatic personnel or an instructed person
under the direction and supervision of qualified personnel
(see "Personnel qualifications" on page 57).
6.1

Checking the valve function

The valve functionality and operating mode can be checked
before commissioning by switching the valves with the manual
override. The electrical signal is disabled.
Damage to the valve due to pushing the manual override!
The manual override is a rotary switch. The manual override
can break off if pushed.
Only actuate the manual override by turning with
a screwdriver.
NOTICE
79
Commissioning
