E 2.4

Recommended Annual Monitor Maintenance Requirements

NOTE: Technical data is subject to modification, revision and improvement without notice.
Table 1: Recommended Annual Monitor Maintenance Requirements
Test Type
Ground Impedance
Test Chassis Leakage Currents
Test Earth Leakage Currents
Test Dielectric Withstand
* See IEC 60601-1 for test methods.
Test Value
ZG < 100 mOhm from the ground pin on the power inlet module
to the Console's exposed metal parts. *
IL < 100 uA in NORMAL Condition.
IL < 500 uA in Single Fault Conditions [300 uA US deviation] *
IL < 500 uA NORMAL Condition [300 uA US deviation]
IL < 1 mA Single Fault Condition *
Test Line and Neutral to Ground @ V = 1500 V~, no breakdown *
E-36
