ZOOM / PAN
RESET
AUTO SOURCE
SELECT
USER NAME
ENTRY
WINDOW
LAYOUT
Controls the zoom in / out of the image.
0:
3:
6:
Controls the PAN in / out of the image
Reset the unit to factory outgoing status
When AUTO SOURCE SELECT is on, the monitor automatically
searches input source, except PIP sub source
Put User's name, etc. into Preset
Change sub window layout (SINGLE, PIP, PBP1, PBP2)
E-27
1: 2:
4: 5:
7: 8:
NOTICE: Maximum ZOOM size is ten times as large
as original size
