Image Menu
❶
IMAGE SIZE - Change the image size (Scaling
mode) (Full; Fill aspect, 1:1; Normal; Video;
Zoom; Video only).
❷
H POSITION - Adjust the horizontal (left or right)
position of the displayed source image
(Range: 0~100).
❸
V POSITION - Adjust the vertical (up or down)
position of the displayed source image
(Range: 0~100).
❹
GAMMA - Adjust GAMMA value (VIDEO,
BYPASS, 1.8, 2.0, 2.2, 2.4, 2.6, PACS).
➎
FILTER - Set the sharpness of the image (Softest,
Soft, Normal, Sharp, Sharpest).
➏
OVER SCAN - Adjust the displayed size ( 0~8)
❼
IMAGE SETTING - Allow selection of one of
five user defined image presets.
Setup Menu
❶
LANGUAGE - Change the OSD language
(8 languages - Korean, English, French, Spanish,
German, Chinese, Japanese, Italian).
❷
OSD POSITION - Change the OSD position.
❸
DURATION - Adjust time until the OSD Menu
will disappear after adjusting the duration
(5, 10, 20, 30, 60, 90, 120, 180, 240 seconds).
❹
RESET SETTINGS - Changes all the OSD values
to factory out-going status.
➎
AUTO SOURCE SELECT - Disable or enable
auto source select. (ON: Searches through all
possible input sources until an active video source
is found. OFF: Video input is manually selected.)
➏
USER NAME ENTRY - Change the name of a
Preset to the Users Name, etc.
