W41-147-004AA.book Page 33 Wednesday, February 18, 2009 2:47 PM

1.16 S-Video (BNC)

Pin No.
1
2
3

1.17 RS232C (D-SUB 9 Pin)

Pin No.
1
2
3
4
5
6
7
8
9

1.18 SDI (BNC)

Pin No.
1
2
3
Assignment
S_VIDEO / Y (Luma)
S_VIDEO / C (Chroma)
Ground
Assignment
No Connection
TXD
RXD
No Connection
Ground
No Connection
No Connection
No Connection
No Connection
Assignment
SDI IN
SDI OUT
Ground
E-33
3
1 2
5
1
6 9
3
1 2
E
