W41-147-004AA.book Page 34 Wednesday, February 18, 2009 2:47 PM
E

1.19 RGBHV / RGBS / YPbPr (BNC)

Pin No.
1
2
3
4 H-Sync / C-Sync
5 V-Sync
6

1.20 OPTICAL (available on VP4726F Monitor Only)

Pin No.
1 OPTICAL Clock
2 OPTICAL Blue
3 OPTICAL Green
4 OPTICAL Red
1.21 GPIO
Pin No.
1 PIP Swap
2 PIP, PBP, PB2 Select
3 Record Indicator
4 Gnd
Assignment
RGBS Y Pb Pr
Red Pr
Green Y
Blue Pb
No Connection
No Connection
Ground
Assignment
Assignment
6
R/Pr G/Y B/Pb
1 2 3
1 2
E-34
C-SYNC/HS VS
4 5
3 4
