PIP SOURCE
E
PIP SIZE
PIP POSITION
Select PIP source input. You can change other sub windows through OSD
PIP menu. The table below is a PIP matching table with main and sub
window.
Input Source DVI DVI
Optical Digital
DVI Optical X 0
DVI Digital 0 X
DSUB Analog 0 X
SDI 0 0
YPbPr 0 X
RGBS 0 X
CVIDEO 0 0
SVIDEO 0 0
0 : Support up to UXGA, 60Hz (162MHz)
1
Change PIP mode sub window size
25% / Panel Size
CAUTION: Do not change input Source aspect ratio. The PIP image size
is changeable depending on input timing.
Change PIP mode sub window position
E-28
Sub Window
DSUB SDI YPbPr RGBS
Analog
0 0 0 0
X 0 X X
X 0 X X
1
0 X 0 0
1 1 1
X 0 X X
1
X 0 X X
1
0 X 0 0
0 X 0 0
33% / Panel Size
CVIDEO SVIDEO
0 0
0 0
0 0
X X
0 0
0 0
X X
X X
