1.14 DVI In, Out (24 DVI-D)

Pin No. Assignment
1 T.M.D.S. Data 2-
2 T.M.D.S. Data 2+
3 T.M.D.S. Data 2 Shield
4 No Connection
5 No Connection
6
7
8 No Connection
9 T.M.D.S. Data 1-
10 T.M.D.S. Data 1+
11 T.M.D.S. Data 1 Shield
12 No Connection

1.15 C-Video (BNC)

Pin No.
1
2
Pin No.
13
14
15
16
17
DDC Clock 18
DDC Data 19
20
21
22
23
24
Assignment
Composite
Ground
Assignment
No Connection
+5V Power
Cable Connection
Check
Hot Plug Detect
T.M.D.S. Data 0-
T.M.D.S. Data 0+
T.M.D.S. Data 0
Shield
No Connection
No Connection
T.M.D.S. Clock
Shield
T.M.D.S. Clock+
T.M.D.S. Clock-
