E 1.9

On-Screen Display Menus

1.9.1

DSUB ANALOG/RGBS Input Source

Adjust Menu
❶
BRIGHTNESS - Increase or decrease the
brightness (Range: 0~100).
❷
CONTRAST - Increase or decrease the contrast
(Range: 0~100).
❸
CLOCK - Increase or decrease the sampling
frequency (Range: 0~100).
❹
PHASE - Increase or decrease the phase level
(Range: 0~100).
➎
BACK LIGHT - Increase or decrease the back
light dimming level (Range: 0~100).
➏
AUTO ADJUST - Fit to the most appropriate
screen on the D-SUB Analog signal.
Color Temp Menu
❶
MODE - Change the color temperature mode:
6500K, 5600K, USER. When USER is selected, a
sub-menu displays allowing the user to adjust the
RED, GREEN or BLUE balance.
❷
RED - Red balance- Only works with USER mode
(Range: 0~100).
❸
GREEN - Green balance- Only works with USER
mode (Range: 0~100).
❹
BLUE - Blue balance- Only works with USER
mode (Range: 0~100).
E-10
