Emotron DIGIFLUX CF Betriebsanleitung Seite 24

F006
0V/0mA
Fig. 8 Reference input, example using F029
F006
(Fmax)
F007
(Fmin)
F026
0V/0mA 2V/4mA
Fig. 9 Reference input, calculation formula 1
F006
(Fmax)
F007
(Fmin)
2V/4mA
0V/0mA
F027
Fig. 10 Reference input, calculation formula 2
22 EINSTELLUNGEN
F029=1
10V/10mA
Can be used with signal type
4-20mA, 1-5V or 2-10V
when F007>10Hz:
F026= F007 -
10V/10mA
Can be used with signal type
4-20mA, 1-5V or 2-10V
when F007<10Hz:
F027= (4 -
(Result in %)
10V/10mA
(F006*F028-F007)
4
(F007*16)
)/20
F006*F028-F007
