3.8

VIBRATION LEVEL_________________________________________________________

The mower was tested for hand and arm vibration levels.
The operator was in the normal position to drive the
vehicle, with two hands on the steering mechanism. The
engine was in operation and the cutting device was in
rotation, while the mower was not moving.
The Machinery Safety Directive 2006/42/EC
By compliance to:
Acceleration Level
Tri-King 67069, 67146
The mower was tested for Whole Body vibration levels.
The operator was in the normal position to drive the
vehicle, with two hands on the steering mechanism. The
cutting device was in rotation with the mower driven in a
straight line at 6 Km/hr on a level and cut lawn.
Whole Body
Acceleration Level
Tri-King 67069, 67146
Tri-King
Hand/Arm
Maximum Left Hand or Right Hand Accelerations m/s
Tri-King
The Lawnmower Standard BS EN ISO 5395-3
Referenced to Hand/Arm: BS EN ISO20643:2008
Information Supplied for Physical Agents Directive 2002/
44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2001)
67069, 67146
Mean Value of X, Y, Z Aeq
2.47 ± 0.6
The Machinery Safety Directive 2006/42/EC
By compliance to:
Whole Body EN1032:2003
Information Supplied for Physical Agents Directive 2002/
44/EC
By reference to:
Whole Body Standards BS EN ISO 2631-1 (1997)
67069, 67146
Maximum Seat Pad Accelerations m/s
Mean Value of X, Y, Z Aeq
.329 ± 0.056
SPECIFICATIONS
