Installation using buffer storage tanks
If required by the application, the heat pump can also be connected to the heating / cooling system using a buffer separator tank.
To do so, it is equipped with two temperature probes that are used to control a buffer storage tank for heating and a buffer storage
tank for cooling. In installations where there is only one buffer storage tank for heating and cooling, both probes have to be
installed in the storage tank. Install the temperature probes at the points where heating / cooling production begins. Heating /
cooling production is stopped by the return temperature probe installed inside the heat pump.
1
2
1
2
Outlet units
These can manage as many as four different outlet temperatures. This is done by managing one direct outlet unit and three
combined outlet units. The combined outlet units have to use modulating 3-way valves with an analogue signal of 0-10Vdc. Each
outlet unit has independent terminals for heating and cooling demands. These signals are supplied with 24Vac or 24Vdc voltage.
DO13
1 1
DO13
2 2
T AI16
Figure 1.10. Wiring scheme using two buffer storage tanks.
1 1
2 2
AI15
T
AI16
T
Figure 1.11. Wiring scheme using a single buffer storage tank.
41
Installer manual ecoGEO
T
T DI6
DO6
DO5 AO3
AI15
T
DG1
DO10
DO12
DI5 DI7
T T
T DI6 T DI8
AI12 AI13
T
DO6 DO14
DO5 AO3 AO4
SG2
DG1
DO10
FBus2
DI5 DI7 DI9 DI11
T T T
T DI8 T DI10 T DI12
AI12 T AI13 T AI14 T
DO14 DO15
AO4 AO5
SG2 SG3 SG4
FBus2
DI9 DI11
T T
T DI10 T DI12
AI14
T T
DO15
AO5
SG3 SG4
