606 U/D torch
Allows the management of the external parameter
(CH1) (parameter selected).
751 Current reading
Allow the real value of the welding current to be dis-
played.
Allows the welding current display method to be set
(consult the "Interface personalisation" section).
752 Voltage reading
Allows the real value of the welding voltage to be dis-
played.
Allows the welding voltage display method to be set
(consult the "Interface personalisation" section).

3.6 Programs screen

1 General
Allows the storage and management of 60 welding pro-
grams which can be personalised by the operator.
1 Process of the selected program
2 Welding methods
3 Current pulsation
4 Number of the selected program
5 Main parameters of the selected program
6 Description of the selected program
2 Program storage
Enter the "program storage" menu by pressing button
(4) for at least 1 second.
Select the required program (or the empty memory) by
rotating the encoder.
Program stored
Memory empty
Cancel the operation by pressing button (2)
Save all the current settings on the selected program by
pressing button (3)
Introduce a description of the program.
- Select the required letter by rotating the encoder.
- Store the selected letter by pressing the encoder.
- Cancel the last letter by pressing button (1)
Cancel the operation by pressing button (2)
Confirm the operation by pressing button (3)
The storage of a new program on an already occupied
memory location requires cancellation of the memory
location by an obligatory procedure.
Cancel the operation by pressing button (2)
Remove the selected program by pressing button (1)
.
Resume the storage procedure.
3 Program retrieval
Retrieve the 1st program available by pressing button
(4) .
.
.
.
.
.
.
