Set a numerical code (password) by rotating the encoder.
Confirm the change made by pressing the encoder button.
Save and exit the current screen by pressing button (4)
Cancel the operation by pressing button (3)
The carrying out of any operation on a locked control panel
causes a special screen to appear.
- Access the panel functionalities temporarily (5 minutes) by
rotating the encoder and entering the correct password (5).
Confirm the change made by pressing the encoder.
- Unlock the control panel definitively by entering set-up (fol-
low the instructions given above) and bring back parameter
551 to "off".

3.9 External controls management

Allows the setting of the welding parameters management
method by the external devices (RC, torch...).
Enter set-up by pressing the encoder key for at least 3 seconds.
Select the required parameter (602).
Enter the "External controls management" screen by pressing
the encoder button.
Select the required RC remote control output (CH1, CH2, CH3,
CH4) by pressing button (1).
Select the required parameter (Min-Max) by pressing the
encoder button.
Adjust the required parameter (Min-Max) by rotating the
encoder.
Save and exit the current screen by pressing button (4)
Cancel the operation by pressing button (3)

3.10 Alarms screen

Allows the intervention of an alarm to be indicated and provides
.
the most important indications for the solution of any problem
.
encountered.
1 Alarm icon
2 Alarm code
3 Alarm type
Alarm codes
E01, E02, E03
E11, E19
E14, E15, E18
E17
E20
E21
E27
E28
E38
E39, E40
E43
.
E99
.
Temperature alarm
System configuration alarm
Program not valid alarm
Communication alarm (µP-DSP)
Memory fault alarm
Data loss alarm
Memory fault alarm ( )
Memory fault alarm ( )
Undervoltage alarm
System power supply alarm
Coolant shortage alarm
General alarm
