Anziehdrehmomente Promag P für ANSI
Nennweite
[mm] [inch]
25 1"
25 1"
40 1 1/2"
40 1 1/2"
50 2"
50 2"
80 3"
80 3"
100 4"
100 4"
150 6"
150 6"
200 8"
250 10"
300 12"
350 14"
400 16"
450 18"
500 20"
600 24"
Anziehdrehmomente Promag P für JIS
Nennweite
[mm]
25
25
32
32
40
40
50
50
65
65
80
80
100
100
125
125
150
150
200
200
250
250
300
300
ANSI Schrauben
Druckstufe
[lbs]
Class 150 4 x 1/2"
Class 300 4 x 5/8"
Class 150 4 x 1/2"
Class 300 4 x 3/4"
Class 150 4 x 5/8"
Class 300 8 x 5/8"
Class 150 4 x 5/8"
Class 300 8 x 3/4"
Class 150 8 x 5/8"
Class 300 8 x 3/4"
Class 150 8 x 3/4"
Class 300 12 x 3/4"
Class 150 8 x 3/4"
Class 150 12 x 7/8"
Class 150 12 x 7/8"
Class 150 12 x 1"
Class 150 16 x 1"
Class 150 16 x 1 1/8"
Class 150 20 x 1 1/8"
Class 150 20 x 1 1/4"
JIS
Druckstufe Schrauben
10K 4 x M 16
20K 4 x M 16
10K 4 x M 16
20K 4 x M 16
10K 4 x M 16
20K 4 x M 16
10K 4 x M 16
20K 8 x M 16
10K 4 x M 16
20K 8 x M 16
10K 8 x M 16
20K 8 x M 20
10K 8 x M 16
20K 8 x M 20
10K 8 x M 20
20K 8 x M 22
10K 8 x M 20
20K 12 x M 22
10K 12 x M 20
20K 12 x M 22
10K 12 x M 22
20K 12 x M 24
10K 16 x M 22
20K 16 x M 24
Proline Promag 10
Max. Anziehdrehmoment [Nm]
PTFE
11
14
24
34
47
23
79
47
56
67
106
73
143
135
178
260
246
371
341
477
Max. Anziehdrehmoment [Nm]
PTFE
32
32
38
38
41
41
54
27
74
37
38
57
47
75
80
121
99
108
82
121
133
212
99
183
