Electrical Installation
Electric power supply
Terminal 10 / red
Terminal 9 / blue
Terminal 8 / pink
Terminal 7 / brown
INSTALLATION
= +12 V
= GND
= +12 V Illumination
= GND Illumination
red
blue
pink
brown
