VLW= Distance Travelled through the Water
$IIVLW,20.5,N,3.3,N
$IIVLW,a, N, b ,N
a Total cumulative distance
N Nautical Miles
b Trip distance since reset
Maintenance of the VDO LOGIC LOG/DEPTH
The display head is maintenance-free. To clean it, use a moist lint-free
or antistatic cloth. Do not use any cleaning agents.
The paddle-wheel and axle assembly of the transducer will have to be ex-
amined for wear and tear once every season. If play is found to be excessi-
ve, both the paddle wheel and the axle will habe to be replaced (see page
94).
The O-rings of the transducers will have to be checked for wear, embrit-
tlement and damage at regular intervals (twice per boating season). The
slightest indication of any such shortcoming makes it necessary to re-
place both O-rings.
Part No.:
Paddel wheel with axle, to 20 kn, km/h, mph
Paddel wheel with axle, over 20 kn, km/h, mph
O-Ring for Log Transducer
O-Ring for Depth Transducer
88
DATA FORMAT/ MAINTENANCE
(20.5 nm)
(3.3 nm)
270.023/005/003
270.023/005/005
N05 800 374
N05 801 418
