Technical Data

LOG
Measuring principle:
Calibration:
Total distance:
Trip distance:
Installation diameter of hull sleeve: 39 mm
Maximum hull thickness for hull sleeve: 30 mm
DEPTH
Range of application:
Measuring principle:
Frequency:
Sending power:
Dial graduation:
Shallow alarm:
Navigation alarm:
Maximum hull thickness for hull sleeve: 39 mm
Maximum hull thickness for internal installation: 12 mm
GENERAL
Power supply:
Operating temperature: -10 oC to +60 oC
Current consumption:
Type of protection:
EMC protection:
Data output:
Output rate:
Dimensions:
DATA
Speed through water
Display depending on type
Pulse count by Hall sensor
Automatic or manual
0 to 99,999 km, nm or miles (US)
0 to 999.99 km, nm or miles (US)
Depth under keel or under water
indication range 0 to 80 m
0 to 20 m in steps of 0.1 m
20 to 80 m in steps of 1.0 m
0.5 to 80 m depending on the nature of the
surface and mounting.
Ultrasound propagation time
200 kHz
about 40 W rms, about 320 W peak-peak
Analog indication (depth under keel)
0 to 8 m, adjustable in steps of 0.1 m
0 to 80 m, adjustable in steps of 1.0 m
10.8 V to 15 V DC
about 80 mA without lightin
about 120 mA with lightin
IP 65 at front per DIN 40050
CE: EN 50081-1, EN 50082-1
VDO LOGIC bus
NMEA 0183
about 1 value per second
Indicating instrument:
125 x 125 x 23 mm
Installation depth
Installation diameter 85 mm
Technical modifications reserved
60 m
103
