4.2 Commissioning of a
Gearless Permanent
Magnet Machine
The following procedure is recommended for the commissioning of a
KEB COMBIVERT F4-F lift version 3.0 with a gearless permanent
magnet machine:
Adjust the parameters in ascending sequence, as this initiates partial
presettings of the unit. Start with the selection of the motor and the
resolution and adjustment of the lift data (LF-parameter). Save the
adjusted data by activating the „ENTER key".
When using a synchronous machine with Hiperface-encoder (inverter
part no. xx.F4.Fxx-xi5x), the motor, encoder and control data are
automatically transferred from the encoder to the inverter at the first
switch on. However, the encoder must be preset with the data. Please
inquire at your motor manufacturer, whether this has been done. If
the data is stored in the encoder, the entire „dr" and „EC"-parameters
as well as LF.30 - LF.36 need not to be entered in the inverter anymore.
LF.00: Enter password (440)
LF.02: Enter setpoint setting/rotation setting
1 = Binary coded setpoint setting
2 = Input coded setpoint setting
3 = Analog setpoint setting 0...+10V
4 = Analog setpoint setting -10...+10V
LF.04: Adjust value "1"
LF.06: Adjust value "1"
LF.20: Enter system speed in m/s
LF.21: Enter the diameter of the traction sheave in mm, if necessary,
remeasure
LF.22: Enter gear reduction 1
LF.23: Enter rope suspension (1 for 1:1, 2 for 2:1 etc.)
LF.24: Enter nominal load (lifting capacity) of the cabine in kg
LF.31 to LF.33: Enter speed controller data (Use pracmatical values
or inquire about adjustment at KEB.)
LF.40: Enter correction speed in m/s
LF.41: Enter crawl speed in m/s
LF.42: Enter rated speed in m/s
LF.43: Enter inspection speed in m/s
