Installation and Connection

2. Installation and Connection
2.1

Summary

2.1.1 Housing Size D - E

Optional Operator
with 9-pole Sub-D Socket
Parameter Interface
Connection
Connection of control terminal
9-pole Sub-D Socket
15-pole Sub-D Socket
Connection of incremental encoder
2.1.2 Housing Size >= G
Optional Operator
with 9-pole Sub-D Socket
Parameter Interface
15-pole Sub-D Socket
Connection of incremental encoder
9-pole Sub-D Socket
Connection
Connection of control terminal
Observe the maximal width of
connectors for X3A and X3B
X2A
X3B
OPTION
X3A
X3A
X3B
OPTION
X2A
GB
GB - 5
