Parameter description
CP.09 Output voltage
Co-domain
0...778 V

3.2.3 Basic Adjustment of the Drive

The following parameters determine the fundamental operating data of the drive and must be adjusted for the
initial commissioning (see chapter 5 "Start-up" ). They should be checked and/or adapted to the application.
GB
CP.10 Speed control configuration
Input
0
1
2
3
4
5
6
7...127
CP.11 DASM rated motor speed
Co-domain
0...64000 rpm
CP.12 DASM rated frequency
Co-domain
0.0...1600.0 Hz
CP.13 DASM rated current
Co-domain
0.0...710.0 A
CP.14 DASM rated voltage
Co-domain
120...500 V
CP.15 DASM cos (phi)
Co-domain
0.50...1.00
GB - 14
Description
Display of the actual output voltage in volt.
Setting Function
x off (open loop operation)
-reserved-
-reserved-
off (open loop operation)
Speed control (closed loop operation)
Torque control (closed loop operation)
Torque-/speed control (closed loop
operation)
off (open loop operation)
Setting Description
see 3.3 Adjustment of rated motor speed according to the name plate. The factory
setting depends on the unit size ( see 3.3 „Factory Settings").
Setting Description
see 3.3 Adjustment of the rated motor frequency according to the name plate. The
factory setting depends on the unit size ( see 3.3 „Factory Settings").
Setting Description
see 3.3 Adjustment of the rated motor current according to the name plate and the
connection (Y / ∆). The factory setting depends on the unit size (see 3.3
„Factory Settings").
Setting Description
see 3.3 Adjustment of the rated motor current according to the name plate and the
connection (Y / ∆). The factory setting depends on the unit size (see 3.3
„Factory Settings").
Setting Description
see 3.3 Adjustment of the motor cos(phi) according to the name plate. The factory
setting depends on the unit size ( see 3.3 „Factory Settings").
Description
With this parameter the basic setting of
the speed controller is determined.
