7. Quick Reference
Parameter
CP.00 Password Input
CP.01 Encoder 1 speed
CP.02 Setpoint display
CP.03 Inverter state
CP.04 Apparent current
CP.05 Peak apparent current
CP.06 Actual torque
CP.07 Actual DC voltage
CP.08 Peak DC voltage
CP.09 Output voltage
CP.10 Speed control configuration
CP.11 DASM Rated speed
CP.12 DASM rated frequency
CP.13 DASM rated current
CP.14 DASM Rated voltage
CP.15 DASM Rated cos (phi)
CP.16 DASM Rated power
CP.17 Load motor dependent parameter
CP.18 Boost
CP.19 rated frequency
CP.20 Encoder 1 (inc/r)
CP.21 Encoder 1 rotation
CP.22 Maximum speed
CP.23 Step value 1
CP.24 Step value 2
CP.25 Acceleration time
CP.26 Deceleration time
CP.27 S-curve time
CP.28 Torque reference source
CP.29 Absolute torque reference
CP.30 KP speed
CP.31 KI speed
CP.32 Switching frequency
CP.33 Relay output 1 / Function
CP.34 Relay output 2 / Function
CP.35 Reaction to limit switch
CP.36 Reaction to external fault
Setting range Resolution
0...9999 1
— 0.125 rpm
— 0.125 rpm
— 1
— 0.1 A
— 0.1 A
— 0,01 Nm
— 1 V
— 1 V
— 1 V
0 (off)...5 1
0...64000 rpm 1 rpm
0.0...1600.0 Hz 0.1 Hz
0.0...710.0 A 0.1 A
120...500 V 1 V
0.50...1.00 0.01
0.35...400.00 kW 0.01 kW
0...2 1
0.0...25.5 % 0.1 %
0...400 Hz 0.0125 Hz
1...16383 inc. 1 inc.
0...19 1
0...4000 rpm 0.125 rpm
+4000 rpm 0.125 rpm
+4000 rpm 0.125 rpm
0.00...300.00 s 0.01 s
-0.01...300.00 s 0.01 s
0.00 (off)...5.00 s 0.01 s
0...5 1
+10000.00 Nm 0,01 Nm
0...32767 1
0...32767 1
2/4/8/12/16 kHz —
0...84 1
0...84 1
0...6 1
0...6 1
↵
