Telephoning

• If the PBX is connected to a router that works as a DHCP server and allocates IP
addresses to the devices connected (default setting on most routers), you can access the
PBX via two IP addresses:
1. Via the permanent IP address 169.254.1.240 from the APIPA address range.
2. Via the IP address allocated by the DHCP server.
Note: If the permanent IP address from the APIPA address range is not working, you will
first have to learn the IP address allocated by the DHCP server. You have the following
options:
• If the UPnP service is installed and activated on the PC (e. g. on Windows 8), the PBX
can be found and selected in the network environment as "COMpact 5x00" device.
• You can use a network scanner (f. e. Angry IP Scanner).
Important: If you wish to operate the PBX in a network where IP addresses are allocated
permanently, you must first adapt the IP configuration of the PBX for operation in the
network. For this purpose, you must first create one of the connection and network
environments described above. It is not possible to change the network configuration by
telephone without prior activation of the system.

Opening the Configuration Manager

Requirements:
• PC with a min. screen resolution of 1024 x 768
• Recommended Browser: Mozilla Firefox (current version), Google Chrome (current
version)
1. Enter the IP address of the PBX in the address field of the browser. Example for entering
the permanent IP address: https://169.254.1.240.
Since the PBX forces an HTTPS connection, your browser will provide a safety warning
(because of the missing safety certificate).
2. If necessary, transmit the safety certificate to your working environment (user and
browser profile).
3. Click with wizard (recommended).
4. Use the configuration wizard to carry out the system activation and configure the basic
settings.
Telephoning

Outgoing Calls/Exchange Line Request

When dialling phone numbers, the exchange line request type configured for the subscriber
must be noted. The PBX distinguishes three types of exchange line requests:
Automatic exchange line request (factory setting): Neither for the internal nor for the
external number a prefix is required (exception: ** for targeted VoIP access). The PBX
50
COMpact 5200/5200R/5500R - Instructions V02 01/2018
