Environmental Requirements

Humidity
Connection Options on the COMpact CPU Module (Basic Assembly Slot A)
Extension Options on the Basic Unit
Connection Options on the COMpact 4FXS Module
Connection Options on the COMpact 2BRI Module
COMpact 5200/5200R/5500R - Instructions V02 01/2018
10 to 90 %, non-condensing
1 Ethernet port, connection via RJ-45 socket,
4 (COMpact 5200/R) or 8 (COMpact 5500R) VoIP
channels for internal IP and Internet telephony, SIP-
compliant in accordance with RFC 3261; support for VoIP
Codecs G.711 (ì-Law/a-Law), G.726, iLBC
thereof one channel usable for voice mail functions with
one voice mailbox)
Important: It is not possible to use the voice mail channel
without inserted USB memory stick (not included in the
scope of delivery).
1 USB host port, connection via USB A socket
5 variable slots (Slot B, C, 1, 2, 3) for the modules:
COMpact 4FXS Module
COMpact 2BRI Module
COMpact 2FXO Module
1 slot (Slot 4) reserved for future extension
4 internal analogue ports (1, 2, 3, 4), connection via RJ-45
socket or spring clamp connection (2-core)
2 ISDN ports (1, 2), connection via RJ-45 socket or spring
clamp connection (4-core S
via jumper optionally switchable as an external S
internal S port and internal U
0
via DIP switch terminators switchable
Important Information
, 2-core U ),
0 P0
port
P0
port,
0
