Important Information
systems and/or nuclear facilities. The device may only be used for these purposes with
prior written permission from the manufacturer in each individual case.
Important: Improper use may cause, for example, functional restrictions or interference,
the destruction of the device or, in a worst-case scenario, personal injury.
• If you are still uncertain about how to use the product properly after reading the chapter
below, please contact your specialised dealer.
• Read the instructions for the device and keep them for future reference.
• Some of the functions require an additional hardware extension, a software expansion
(activation), activation by the network provider, and/or configuration via the
Configuration Manager.
The COMpact 5200, COMpact 5200R and COMpact 5500R devices are telecommunication
systems; they will be referred to as PBXs in the following. These PBXs connect various
internal devices with various public telecommunication networks, thereby enabling external
and internal calls. For this purpose, the PBXs provide a number of different ports/interfaces.
The PBXs are structured modularly. They are suitable for use in the commercial sector (small
to midsize companies).
The COMpact 5200 is a PBX with a plastic casing available for wall mounting.
The COMpact 5200R and COMpact 5500R are PBXs with a 19" casing available for
installation in a 19" rack. They are suitable for use in structured IT/telecommunication
networks.
The PBXs are intended to be operated in closed rooms. In addition, all of the devices
connected to the system must be located in the building.

Technical Data

Power Supply
Rated voltage
Rated current
Protection class
Power (depending on the
configuration level of the PBX)
Expansion modules
Environmental Requirements
Operation
Operating the modules
Storage and shipping
34
230 VAC +/-10 %, 50 Hz
Max. 0.4 A
I
COMpact 5200: min 8 W, max. 70 W
COMpact 5200R/5500R: min. 10 W, max. 70 W (min. 8 W
if fan is off)
Power supply from the PBX
0 to +40° Celsius
Protect unit against direct sunlight!
Installed in the PBX casing
-20 to +70° Celsius
COMpact 5200/5200R/5500R - Instructions V02 01/2018
