Sync Output; Communication Port - PeakTech 4035 Bedienungsanleitung

Sweep Time
Marker
Trigger Source
Continuous Burst
Single Burst
External Trigger Input( FSK,
Burst, Sweep)
Input Level
Pulse Width
Input Impedance
CLOCK REFERENCE
External Reference Input
Lock Range
Level
Impedance
Internal Reference Output
Frequency
Level
Impedance

SYNC OUTPUT

Waveform
Level
Impedance
COUNTER
Testing Function
Frequency
Resolution
Period Pulse Width
Burst Count
Accuracy
Input Amplitude
Input Impedance
Coupling
Trigger Level
Sensitivity
Low Filter

COMMUNICATION PORT

Mode
Power Amplifier
Maximum output power
Maximum output voltage
10ms ~ 60s
internal
1 Hz – 100 MHz
6 digits / s
100 mVpp – 20 Vpp
8W (8), 2W (50)
30 Vpp
-118-
1 ms to 500 s
Falling edge of Sync Output
Internal
Manual, External
TTL-compatible
> 100 ns
10 kΩ
10 MHz ± 35 kHz
2 Vpp to 5 Vpp
1 kΩ
10 MHz
＞2 Vpp
50Ω
Pulse
TTL-compatible
50Ω
frequency, period,
width, duty cycle, burst count
0.1Hz to 200 MHz
6 digits / s
100ns to 20s
1 to 100000000 cyc
± 20 ppm
100 mVrms to 7 Vrms
1 MΩto 50Ω
AC / DC
－4 V to 4 V
50% to 100%
on/off
USB Host,
Device，RS232
4W (8), 2W (50)
20 Vpp
pulse
USB
