11. Specifications
WAVEFORMS
Standard Waveforms
Arbitrary Waveforms
Waveform Length:
Amplitude Resolution
Sample Rate
Non-Volatile Memory
FREQUENCY
CHARACTERISTICS
Range Settings
Sine
Square
Ramp
Pulse
Arb
Resolution
Accuracy:
SINEWAVE SPECTRAL
PURITY
Harmonic Distortion
Spurious（non-harmonic）
Phase Noise (30 kHz band)
Total Harmonic Distortion
NON-SINEWAVE
CHARACTERISTIC
Square Wave
Duty Cycle
Edge Time
Overshoot
®
PeakTech 4035
CH A: Sine, Square, Pulse,
DC
CH B: 22 types including
sine, square,
sawtooth, stair stc.
CH A: 3 to 16 k points
CH B: 1024 points
10 bits (including sign)
180 MSa/s
CH A: 40 mHz – 5 MHz
CH B: 10 mHz – 1 MHz
(for other waveforms: 10 mHz
– 50 kHz)
CH A: 40 mHz – 30 MHz
40 mHz – 5 MHz
CH A: 40 µHz (40 µHz~1
kHz); 40 mHz
CH B: 10 mHz
-5
CH A: ± (5x10 + 40 mHz)
>50 dBc (DC~1MHz)
>40 dBc (1MHz~20MHz)
>30 dBc (20MHz~30MHz)
≤ 0.5% @ 20Hz to 200 kHz
50,00%
<20 ns
≤ 5%
-115-
®
PeakTech
Sine, Square, Ramp, Pulse,
DC
triangle,
5 function waveforms such as
Exponential,
Sin(x)/x
3 to 8 k points
14 bits (including sign)
100 MSa/s
10,8 k waveforms
1 μ Hz - 25M Hz
1 μHz - 15 MHz
1 μHz - 1 MHz
1 μHz - 5 MHz
1 μHz - 5 MHz
1 μHz
± 20 ppm, 18°C to 28°C
>50 dBc (DC~1MHz)
>45 dBc (1MHz~15MHz)
>40 dBc (15MHz~25MHz)
>60 dBc (DC~1MHz)
>50 dBc (1MHz~25MHz)
≤60 dBc @ 10 MHz
≤ 0.2% @ DC to 20 kHz
50,00%
20 ns to 200 ns
≤ 5%
4050
Logarithm,
