3.1.1. The front panel of PeakTech
2.
1.
Power
2.
Softkeys
3.
Display screen
4.
Option softkeys
5.
Count input termination
6.
Output softkey
The rear panel at a glance
1.
Power receptacle
2.
RS232 interface
3.
External modulation input
4.
Trigger In
5.
10 MHz out
®
4050
11.
12. 13.
2.
3.
4.
7.
SYNC output termination
8.
Signal output termination
9.
USB Host
10. Direction keys
11. Model logo
12. Waveform keys
14.
15.
5. 6. 7.
8.
9. 10.
6.
10 MHz in
7.
USB device
8.
Power Amplifier Input
9.
Power Amplifier Output
-67-
13. Functional keys
14. Numeric keys
15. Digital adjusting knob
