Technical Datas - Scheppach Fpts1500 Bedienungsanleitung

FPTS1500
GB-
IE
Technical data
Noise parameters
Measurement conditions
The specified values are emission values and do not necessarily represent
proven working values. Although there is a correlation between emission and
imission levels, it cannot be reliably concluded whether protective measures
are required or not. Factors affecting the imission level present at the working
place include the duration of exposure, the characteristics of the working
room, other sources of noise, etc., e.g. the number of machines and adjacent
procedures. Reliable working values may also vary from country to country.
However, this information is meant to enable the user to evaluate dangers and
risks better.
30
Technical data
Dimensions L x W
x H
Bench size
Bench size with
widener
Bench height with
base frame
ø saw blade
Height adjustment
90°/45°
Tilt range
Cutting speed m/sec
Longitudinal stop
Cutting width left/
right
Weight
Drive
Motor V/Hz
Input power
Mode of operation
Rotational speed
Motor protection
Low voltage circuit
breaker
Plug
Technical changes reserved!
FPTS1500
950 x 850 x 1200 mm
640 x 445 mm
640 x 945 mm
850 mm
250 x 30 x 2,4/1.8 Z 24 WZ
0–73/0–65 mm
90°–45°
80
445 x 640 mm
90/200 mm
24,5 kg
230 V/50 Hz
1200 W S1 / 1500 W S6 40%
S1 / S6 40 %
6000
IP 20
yes
Isolated earth
Technical data
