FPTS1500

Operation

Observe the safety instructions!
Important note: The machine must only be commissioned when the protecti-
on and safety equipment is completely mounted.
Connect the machine to an extraction unit before commissioning.
The extraction cover must be lowered onto the workpiece during each pro-
cess step.
The machine must be set up so that the tip of the highest saw tooth is a little
higher than the workpiece.
All protection and safety equipment must be mounted correctly before swit-
ching on the machine.
The saw blade must be freely moveable.
Check the wood for foreign materials (nails, screws, etc.), if it has been pro-
cessed before. Remove all foreign materials.
Before pressing the main switch, make sure that the saw blade is mounted
correctly and that the moveable parts are smooth-running.
Warning: If you have any doubts, have a specialist set up the machine. It is
dangerous to work based on assumptions.
Switching on and off (Fig. 9)
• Press the green button „I" (1) to switch the machine on. Wait for the blade
to reach its maximum speed of rotation before commencing with the cut.
• Press the red button „0" (2) to switch the machine off.
Adjusting the cutting depth (Fig. 9)
Fig. 9
1 / 2
3
• Adjust the desired cutting
depth by turning the height
adjusting crank(3).
• Turning in counter-clockwi-
se direction increases the
cutting depth.
• Turning in clockwise direc-
tion decreases the cutting
depth.
