FPTS1500

Electrical connection

The installed electric motor is connected and ready for operation. The connec-
tion complies with the applicable VDE and DIN regulations.
The mains connections provided by the client as well as the used extension
cable must comply with these regulations.
Important notes!
The electric 230 V/50 Hz motor is designed
for operating mode 1200 W S1 / 1500 W S6
40%.
If overloaded, the motor switches off auto-
matically. After a cooling-down period (varies
in time), the motor can be switched on again.
Damaged electrical connection cables
Insulation damage often occurs on electrical connection cables.
Reasons are:
• Pressure, if the connection cable is drawn through windows or doors.
• Kinks due to improper fixing or drawing of the connection cable.
• Cuts due to running over the connection cable.
• Insulation damage due to pulling out of the mains socket.
• Ruptures due to aging of the insulation.
Such damaged electrical connection cables must not be used and are a dan-
ger to life due to their insulation damage.
Check electrical connection cables regularly for such damage. Make sure that
the connection cable is not live when checking.
Electrical connection cables must comply with the applicable VDE and DIN
regulations. Only use connection cables with the label H 07 RN.
A label on the connection cable indicating the type is stipulated.
Electrical connection
