2. Package contents
1 40V CORDLESS GARDEN MULTI-TOOL
1 protective cover
1 3-tooth blade
1 pole pruner attachment
1 hedge trimmer attachment
1 strimmer / 3-tooth blade attachment
1 strimmer
1 oil bottle
100 ml saw chain fluid
1 hex key
1 multifunction key
1 carrying harness
1 guard (3-tooth blade)
1 guard (pole pruner)
1 guard (hedge trimmer)
1 set of operating instructions
|
4 English
FR: The product, packaging and
operating instructions are recyclable.
They are subject to extended
3. Appliance description
(For illustrations see fold-out pages)
Fig. A
1 Motor unit
2 Keyhole
3 Start lever
4 Safety lock-out
5 Carrying lug
6 Additional handle
7 Leg protector
8 Shaft tube on motor unit
9 Rotary knob (with washer)
10 Locking button
11 Shaft tube (strimmer attachment)
12 Protective cover
12a Click lock
12b Guard
13 Hex key
14 On/Off switch
15 Speed button
16 Charge level indicator
17 Rotational speed setting
Fig. B
18 Oil bottle
19 Multifunction key
20 3-tooth blade
21 Guard (3-tooth blade)
22 Rotary knob
23 Strimmer
24 Guard (pole pruner)
25 Guard (hedge trimmer)
Fig. C
26 Locking pin
27 Rubber piece
28 Bracket
29 Washer
30 Rotary knob
