2.2 Meter

2.2.1 Front View

No. Description
1 Cable port
2 LCD display
3 Function keys
F1...F4
smartmeter C10
For connecting a DVB-C cable (F-connector) to the meter.
If the cable uses a coaxial connector, use the supplied
adapter F-connector to coaxial connector to connect the ca-
ble.
Displays the TV picture, the menu and the measured values.
Functions vary across menus/submenus.
Functions are indicated at the bottom of the display.
Product Description
51
