Next Level Racing MICROSOFT EDITION Bedienungsanleitung Seite 6

support@nextlevelracing.com support@nextlevelracing.com
1 x STRAIGHT SIDE ARM 1 x SIDE ARM (LEFT)
14 x M4 16mm BOLTS
26 x M6 16mm BOLTS
42 x M8 55mm BOLTS
14 x M8 16mm BOLTS
4 x 20mm KNOBS 1 x M8 70mm BOLT
M8
M6
M5
M4
1 x M4/M6 WRENCH
4 x ALLEN KEYS
1 x M5/M6 WRENCH
1 x 13mm WRENCH (M8) 1 x TURTLE BEACH ADAPTOR
2 x FELT PADS
1 x SUPPORT BRACKET
(30mm x 120mm)
1 x SIDE ARM (RIGHT) 1 x 40mm BARREL SPACER
14 x M4 FLANGE NUTS
8 x M5 FLANGE NUTS
34 x M6 FLANGE NUTS
8 x M5 60mm BOLTS
42 x M8 FLANGE NUTS
6 x SQUARE WASHERS
THREADED STUDS
6 x ADJUSTABLE FEET 1 x BUTTKICKER POLE
6 x VELCRO CABLE TIES
1 x SUPPORT BRACKET
1 x COLLECTIVE BRACKET
MOUNT
6 6
1 x CLAMP PLATE
14 x M4 WASHERS
8 x M5 WASHERS
26 x M6 WASHERS
57 x M8 WASHERS
10 x M8 16mm OUTSIDE
10x M6 20mm
DIAMETER WASHERS
1 x KEYBOARD MAT
1 x MOUSE MAT 2 x TPR ADAPTORS
1 x EXTENDED HOTAS
BRACKET
