HOTAS POLE HEIGHT ADJUSTMENT
35
Loosen the Knobs securing the HOTAS Inner Pole to the HOTAS Outer Pole. Adjust to desired height
and tighten Knobs to lock in place.
HOTAS POLE ANGLE ADJUSTMENT
36
Uninstall the front Bolts, Washers and Flange Nuts securing the HOTAS Plate to the HOTAS Inner Pole. Angle to
the desired position. Bolt through and secure with 1 x Bolt, Washer and Flange Nut previously uninstalled.
CENTRE POLE HEIGHT ADJUSTMENT
37
Loosen the Knobs securing the Inner Centre Pole to the Outer Centre Pole. Adjust the Inner Centre Pole to the
desired height and tighten the Knobs to secure in place. Utilize the multiple threaded inserts for a perfect fit.
Video Instruction: bit.ly/nlrbuild
