6-2-3. Output Cable Length (For analog output only)

There is a correlation between the maximum response speed and output cable length.
Cable length (m)
3
9
15
• The system will not be compliant with EN61000-6-2 if the power supply line exceeds 10 m.
Devise and implement measures to prevent surges.
• The maximum response speed varies depending upon the resistance of the output cable, cable capacity,
receiver load, and so on.
6-6
(E)
Maximum response speed (mm/s)
3000
2330
1660
BL57-RE
