4-4. MODE Switch

Default setting status
(In the case of
output format F, H)
O
N
1
2
3
4
5
6
7
8
9
10
MODE switches
A/B signal output type (Output format F, G)
1, 2
POS. lamps light
4
3
2
1
3
ON ..... B signal is leading
OFF .... A signal is leading
4
ON ..... Reverse direction (default setting established at factory)
OFF .... Forward direction (default setting established at factory)
5
Normally ON
OFF only during reference point adjustment
Output format F: ON ..... 0.1 µm
6
7
ON ..... Outputs reference point signal in single direction only
OFF .... Outputs reference point signal in both directions (However, the
8
ON ..... Hold Mode
OFF .... Automatic Reset Mode
9
ON ..... Reverse direction
OFF .... Forward direction
10
ON ..... 1/4 Reference Point Mode
OFF .... Reference Point Mode
BL57-RE
Default setting status
(In the case of
output format G)
O
N
MODE switch 1
1
MODE switch 2
2
MODE switch 3
3
MODE switch 4
4
5
MODE switch 5
6
MODE switch 6
7
MODE switch 7
8
MODE switch 8
9
MODE switch 9
10
MODE switch 10
MODE switch 1
OFF
ON
OFF
ON
OFF .... 0.05 µm
reference point position is shifted by approximately 4 mm.)
MODE switches
(for various settings)
(Direction switch)
(This setting applies for detection in the forward direction.
It is "ON" for detection in the reverse direction.)
(Resolution setting switch)
(Alarm mode switch)
Fig. 4-4
MODE switch 2
OFF
OFF
ON
ON
Output format G: ON ...... 0.02 µm
OFF .... 0.01 µm
Table 4-1
Analog output type (Output format H)
MODE switch 1 ...... Always ON
MODE switch 2 ...... Always OFF
Always OFF
ON ..... Reverse direction (default
setting established at factory)
OFF ... Forward direction (default
setting established at factory)
Always ON
Always ON
ON ..... Outputs reference point signal
in single direction only
OFF ... Outputs reference point signal
in both directions (However, the
reference point position is
shifted by approximately 4 mm.)
Always OFF
ON .... Reverse direction
OFF .. Forward direction
Always OFF
4-3
(E)
