1-3. Series Models

Neoceram models
Model name
∗
BL57-003RE C
∗
BL57-006RE C
∗
BL57-011RE C
∗
BL57-016RE C
∗
BL57-021RE C
∗
BL57-026RE C
∗
BL57-031RE C
∗
BL57-036RE C
∗
BL57-041RE C
Note:It is possible to use a special specification unit that
has a measuring length of between 420 and 660 mm.
B L 5 7 −
***
Examples
• BL57-026REGC : Neoceram 260 mm, Open type with reference point, A/B signal output (0.02/0.01 µm)
• BL57-006REFB : Soda lime glass 60 mm, Open type with reference point, A/B signal output (0.1/
0.05 µm)
• BL57-026REHB : Soda lime glass 260 mm, Open type with reference point, Analog output (0.4 µm)
1-2
(E)
Measuring length
30 mm
60 mm
110 mm
160 mm
210 mm
260 mm
310 mm
360 mm
410 mm
Table 1-1
R E
Scale material C : Neoceram
Output format F : A/B signal output (0.1/0.05 µm)
Open type (with reference point)
Measuring length (cm)
Model
Fig. 1-1
Soda lime glass models
Model name
∗
BL57-006RE B
∗
BL57-016RE B
∗
BL57-026RE B
∗
BL57-036RE B
∗
BL57-046RE B
∗
BL57-056RE B
∗
BL57-066RE B
∗
BL57-076RE B
∗
BL57-086RE B
∗
BL57-096RE B
∗
BL57-106RE B
Note: It is possible to use a special specification unit that has
a measuring length of between 1070 and 1360 mm.
B : Soda lime glass
G : A/B signal output (0.02/0.01 µm)
H : Analog output (0.4 µm)
Measuring length
60 mm
160 mm
260 mm
360 mm
460 mm
560 mm
660 mm
760 mm
860 mm
960 mm
1060 mm
BL57-RE
